Huazhibei LD-10series LED street light, using high-quality aluminum die casting shell, simple structure,Streamline design, surface spray treatment, high temperature resistance, good weather resistance; optimal integration.The function of heat dissipation, beautiful appearance; using a unique two optical design of the lens, the whole Light intensity, uniform brightness; high temperature resistant silicone rubber seal, seal better equipped with high;A low loss chip imported light source, high thermal conductivity, low luminous decay, pure light color, no ghosting;Isolation of high precision IC control drive, constant current precision, high conversion rate, longer service life.

Applications: highway, city streets, bridges, tunnels, underground tunnels, underground parking lot, railway square, etc.!

Characteristic Parameter:

Model No.	（W） Power	（V） Working Voltage	（λ） Power Factor	（lm） Luminous Flux	(Ra) CRI	(K) CCT	(IP) IP Rate	(℃) ambient temperature	Lamp Structure
LD-10-60W	60	AC85-265	﹥0.9	4800	﹥70	2700-6800	65	-20℃～+50℃	10 Series 3 Parallel * 2

Note: the scope of power error is about 10%; the range of flux error is -10%, some warm white luminous flux will decrease
